RFID Reader

This RFID reader delivers reliable performance with support for both low-frequency (125 kHz) and high-frequency (13.56 MHz) technologies. Featuring integrated antennas and a compact ABS housing, it is designed for seamless integration into a variety of applications.

The device offers flexible connectivity through USB and RS-232, along with optional SAM slots for secure card handling. With multiple operating modes—including keyboard emulation and virtual COM—it easily adapts to diverse system requirements. Its durable design operates effectively across wide temperature ranges, making it suitable for demanding environments.

Key Features:

• Supports 125 kHz (LF) and 13.56 MHz (HF) RFID frequencies
• Integrated antennas within a compact ABS UL94-V0 housing
• USB and RS-232 interfaces for broad compatibility
• Read/write distance up to 100 mm (LF/HF, dependent on environment and transponder)
• Multiple operating modes: USB keyboard emulation, virtual COM port, CCID, PC/SC 2.01
• Wide operating temperature range: –25°C to +70°C
• Low power consumption with sleep mode support
• Long service life with MTBF of 500,000 hours
• Certifications include CE, FCC, IC, UL listed, TAA compliant, REACH, and RoHS-III

Additional Highlights:

• Compatible with more than 60 RFID technologies
• Dual-frequency support (LF & HF) and NFC capability
• SDK available for developing custom applications
• Supports up to 18 KB flash storage for secure non-volatile data
• Enables transparent data exchange with RFID media
